ASROCK TRX50 WS AMD TRX50 Ryzen 7000 EATX DDR5 sTR5 Threadripper Motherboard

• Unique Feature
  Superb Productivity
  – PCIe Gen5 (Graphics, M.2)
  – Quad Channel DDR5
  Rock-Solid Durability
  – Ultra Low-Loss PCB
  – 18 3 3 Power Phase, 110A SPS for VCore
  – Pre-Installed I/O Shield
  – 20K Long-lasting Black Caps (high quality and conductive polymer capacitors)
  Ultrafast Connectivity : – 10G LAN, 2.5G LAN, 802.11ax Wi-Fi 6E Module
  EZ Update
  – BIOS Flashback Button
  – ASRock Auto Driver Installer
• CPU
  – Supports AMD Ryzen™ Threadripper™ PRO 7000 and AMD Ryzen™ Threadripper™ 7000 Series Processors
  – Supports AMD Socket sTR5
  – Supports ASRock Hyper BCLK Engine

• Chipset : – AMD TRX50

• Memory
  – Quad Channel DDR5 Memory Technology
  – 4 x DDR5 DIMM Slots
  – Supports DDR5 ECC, buffered memory (RDIMM/ RDIMM-3DS) up to 7600 (OC)
  – Max. capacity of system memory: 1TB
• BIOS : – 256Mb AMI UEFI Legal BIOS with GUI support

• Graphics : – n/a

• Audio
  – 7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
  – Impedance Sensing on Rear Out port
  – Individual PCB Layers for R/L Audio Channel
  – Nahimic Audio
• LAN
  1 x 10 Gigabit LAN 100/1000/2500/5000/10000 Mb/s (Marvell AQC113)
  – Support Wake-On-LAN
  – Support PXE
  1 x 2.5 Gigabit LAN 10/100/1000/2500 Mb/s (Dragon RTL8125BG)
  – Supports Dragon 2.5G LAN Software
  – Smart Auto Adjust Bandwidth Control
  – Visual User Friendly UI
  – Visual Network Usage Statistics
  – Optimized Default Setting for Game, Browser, and Streaming Modes
  – User Customized Priority Control
• Wireless LAN
  – 802.11ax Wi-Fi 6E Module
  – Supports IEEE 802.11a/b/g/n/ac/ax
  – Supports Dual-Band 2×2 with extended 6GHz band support*
  – 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
  – Supports Bluetooth 5.2 High speed class II
  – Supports MU-MIMO

  *Wi-Fi 6E (6GHz band) will be supported by Microsoft^® Windows^® 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows^® Update and software updates once available.
  A 6GHz compatible router is required for 6E functionality.
• Slots
  CPU:
  – 3 x PCIe 5.0 x16 Slots (PCIE1/PCIE3 at x16; PCIE4 at x8)*
  – 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode*
  – 1 x PCIe 4.0 x16 Slot (PCIE5), supports x8 mode*
  Chipset:
  – 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
  – 15μ Gold Contact in VGA PCIe Slots

  * Supports NVMe SSD as boot disks
• Storage
  CPU:
  – 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen5x4 mode*
  – 1 x MCIO PCIe Gen5x4 Connector
  – 2 x SlimSAS SFF-8654 Connectors (PCIe Gen4x4 or 4 x SATA3 6.0 Gb/s)
  Chipset:
  – 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 mode*
  – 4 x SATA3 6.0 Gb/s Connectors

  * Supports NVMe SSD as boot disks
• RAID
  – Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
  – Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*

  * Requires additional M.2 NVMe expansion cards to support RAID 10
• USB
  CPU:
  – 1 x USB 3.2 Gen2x2 Type-C (Rear)
  – 4 x USB 3.2 Gen2 Type-A (Rear)
  Chipset:
  – 2 x USB 3.2 Gen2 Type-C (1 Rear, 1 Front)
  – 4 x USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
  – 4 x USB 2.0 (Front)

  * All USB ports support ESD Protection
• Connector
  – 2 x Thermistor Cable Headers
  – 1 x SPI TPM Header
  – 1 x COM Port Header
  – 1 x Chassis Intrusion and Speaker Header
  – 2 x Addressable LED Headers*
  – 1 x CPU Fan Connector (4-pin)**
  – 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
  – 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****
  – 1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
  – 1 x 3 pin ATX Power Connector*****
  – 2 x 8 pin ATX 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)******
  – 2 x 6 pin PCIe 12V Power Connectors (Hi-Density Power Connector) (for Motherboard)******
  – 1 x 6 pin Graphics 12V Power Connector (Hi-Density Power Connector) (for PCIe card)*******
  – 1 x Front Panel Audio Connector (15μ Gold Audio Connector)
  – 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card)
  – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
  – 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
  – 1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s)
  – 1 x Dr. Debug with LED
  – 1 x Power Button with LED
  – 1 x Reset Button with LED

  * Support in total up to 5V/3A, 15W LED Strip
  ** CPU_FAN1 supports the fan power up to 1A (12W).
  *** CPU_FAN2/WP supports the fan power up to 2A (24W).
  **** CHA_FAN1~3/WP support the fan power up to 2A (24W).
  ***** Plug the Multi PSU Adaptor Cable that comes with the package to ATX_CON1 if you use a secondary PSU.
  ****** It is required to connect both ATX12V1 and ATX12V2; otherwise, the system may not boot up properly.
  ****** It is required to connect all 8 pin and 6 pin 12V Power Connectors when overclocking.
  ******* It is required to connect a 6 pin PCIE 12V Power Cable to GFX_12V1; otherwise, the system may not boot up properly.
• Rear Panel I/O
  – 2 x Antenna Ports
  – 1 x Optical SPDIF Out Port
  – 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
  – 4 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)
  – 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)
  – 2 x USB 3.2 Gen1 Type-A Ports
  – 2 x RJ-45 LAN Ports
  – 1 x Clear CMOS Button
  – 1 x BIOS Flashback Button
  – 1 x Line Out Jack (Gold Audio Jack)
  – 1 x Microphone Input Jack (Gold Audio Jack)
• Software and UEFI
  Software
  – ASRock Motherboard Utility (A-Tuning)
  – ASRock Dragon 2.5G LAN Software
  – ASRock Polychrome SYNC*
  UEFI
  – ASRock Full HD UEFI
  – ASRock Auto Driver Installer
  – ASRock Instant Flash

  *These utilities can be downloaded from ASRock Live Update & APP Shop.
• Accessories
  – 1 x User Manual
  – 4 x SATA Data Cables
  – 1 x ASRock WiFi 2.4/5/6 GHz Antenna
  – 2 x Thermistor Cables
  – 1 x Multi PSU Adaptor Cable
  – 2 x Screws for M.2 Sockets
  – 2 x Standoffs for M.2 Sockets
• Form Factor
  – EATX Form Factor: 12.0-in x 10.9-in, 30.5 cm x 27.7cm
  – 12 Layer PCB
  – 2oz Copper PCB
• OS
  – Microsoft^® Windows^® 11 64-bit
• Certifications
  – FCC, CE
  – ErP/EuP ready (ErP/EuP ready power supply is required)

The specification is subject to change without notice in advance. The brand and product names are tradem
