Deepcool Assassin 4S WH Dual Tower CPU Air Cooler (White) R-ASN4S-WHGPMN-G
Overview :
The ASSASSIN 4S WH provides exceptional performance and is armed with seven 6mm heat pipes and a redesigned 140mm FDB fan. The 4S models eliminate the rear 120mm fan, providing a slimmer, more symmetrical cooler. The white and gray aesethic blend in perfectly with that all-white system.
QUIET OR PERFORMANCE MODE
With a simple slide of a switch, the ASSASSIN 4S WH can morph from a whisper-quiet cooler when low noise is of the utmost importance to the efficient cooling force DeepCool air coolers are known for.
LET IT SHINE!
The shell of ASSASSIN 4S WH is clean, sleek, and helps channel air through the fin towers, while the slimmer profile provides unobstructed clearance for high-profile RGB RAM.
BE COOL, BE CALM
A key factor in the ASSASSIN 4S WH’s extremely silent operation is the use of three-phase, six-pole fan motors with low voltage and power consumption. DeepCool is so confident in our new design that the ASSASSIN 4S WH comes with 6 years of limited warranty coverage!
EXCEPTIONAL BY DESIGN
Featuring seven heat pipes that deliver improved heat transfer through two fin-array heat sink towers for high performance efficiency. The included DM9 thermal paste meets the rigorous standards used in industrial applications.
THE FLOW BELOW
Due to the center 140mm fan sitting deep into the heart of the ASSASSIN 4S WH, there is a lower flow of air that provides additional cooling to the toasty surrounding VRMs.
Application For
Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155
AMD AM5/AM4
Specification :
| Model Number | R-ASN4S-WHGPMN-G |
| Product Dimensions | 116×147×164 mm(L×W×H) |
| Heatsink Dimensions | 140×110×160 mm(L×W×H) |
| Net Weight | 1380 g |
| Heatpipe | Ø6 mm×7 pcs |
| Fan Dimensions | 140×140×25 mm(L×W×H) |
| Fan Speed (Performance Mode) | 500~1800 RPM±10% |
| Fan Airflow (Performance Mode) | 61.25 CFM |
| Fan Air Pressure (Performance Mode) | 3.76 mmAq |
| Overall Noise (Performance Mode) | ≤29.3 dB(A) |
| Fan Speed (Quiet Mode) | 500~1450 RPM±10% |
| Fan Airflow (Quiet Mode) | 48.55 CFM |
| Fan Air Pressure (Quiet Mode) | 2.46 mmAq |
| Overall Noise (Quiet Mode) | ≤22.6 dB(A) |
| Fan Connector | 4-pin PWM |
| Bearing Type | Fluid Dynamic Bearing |
| Motor Type | 6-Pole Fan Motor |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.2 A |
| Fan Power Consumption | 2.4 W |
| Rated Voltage | 12 VDC |
| Power Consumption(Performance Mode) | 3.6 W |
| Power Consumption(Quiet Mode) | 2.4 W |
| Warranty | 6 Years |
