Noctua NF-P14s redux-1500 PWM Case Fan
Noctua redux series NF-P14 fan with 4-pin PWM and 1500 rpm is available in two versions: square frame with model # NF-P14s redux-1500PWM for use in case and radiator cooling, and round frame with model # NF-P14r redux-1500PWM for use on CPU cooling.
The fan features a nine-blade design to achieve outstanding static pressure of up to 1.91 mm H2O and a high airflow of 133.7 m³/h, while supporting fully automatic speed control via PWM for the best balance between cooling performance and noise level. Its industry-grade SSO bearing and over 150.000 hours MTBF rating guarantee exceptional long-term stability and reliability.
It provides trusted Noctua quality at an attractive price point. It’s ideal for high efficiency case, radiator and CPU cooling as well as other applications that require both extended performance headroom and PWM for automatic speed control.
Proven NF-P14 Design
Tens of thousands of quiet cooling enthusiasts around the globe swear by Noctua’s classic NF-P14. Thanks to its impressive quietness, excellent performance and impeccable quality, the NF-P14 has become an established reference for quiet 140mm fans.
Streamlined Redux Edition
The redux product line reissues some of Noctua’s most popular, award-winning models by presenting them in streamlined, accessibly priced packages. All redux edition products are industry proven, time-tested models that helped to found Noctua’s reputation as a first-tier supplier of premium grade low noise cooling equipment.
Square 140mm Frame
The square 140mm frame of the NF-P14s features standard 140mm mounting holes (124.5mm spacing), which makes it a premium grade replacement for common 140mm case fans and perfect for use on 140mm water cooling radiators, where its square shape will ensure full coverage and best pressure performance.
Pressure-optimized Nine-Blade Design
Specifically developed for high-impedance applications such as CPU coolers, water-cooling radiators or cases with tight fan grills, the NF-P14’s nine-blade impeller provides outstanding pressure and airflow performance.
Vortex-Control Notches
Noctua’s signature Vortex-Control Notches split up trailing edge vortices and thus spread the fan’s noise emission over a wider range of frequencies. This measure makes the fan sound more pleasant to the human ear.
Custom-designed PWM IC with SCD
Supporting fully automatic speed control via PWM, the fan uses Noctua’s custom-designed NE-FD1 PWM IC that integrates Smooth Commutation Drive (SCD) technology. By providing smoother torque impulses, SCD suppresses PWM switching noises and thus makes the fan quieter at lower speeds.
SSO-Bearing
Combining the proven concept of hydrodynamic bearings with an additional magnet that supports the self-stabilization of the rotor axis, Noctua’s time-tested SSO-Bearing technology has become synonymous with supremely quiet operation and exceptional long-term stability.
Optional Accessories
Users can choose from Noctua’s wide range of optional accessories such as anti-vibration mounts, Low-Noise-Adaptors, y-cables, 3:4 pin adaptors or extension cables to upgrade redux edition fans according to their individual needs.
Specification :
Model
Brand : Noctua
Model : NF-P14s redux-1500 PWM
Details
Fan Size : 140x140x25 mm
Bearing Type : SSO
RPM : 1500 RPM
Air Flow : 133,7 m³/h
Noise Level : 25,8 dB(A)
Power Connector : 4 Pin
Features
Max. Input Power: 2,4 W
Max. Input Current: 0,2 A
Voltage: 12 V
MTBF: > 150.000 h
Scope of Delivery:
Fan
4 Fan Screws
