NZXT C750 750W 80 PLUS Gold Fully Modular ATX Power Supply PA-7G1BB-IN
Overview :
This PSU delivers 750 watts of clean, stable power which is plenty for most gaming needs while providing headroom for future upgrades and is an ideal wattage to start overclocking.
- Modular design lets builders use only the cables they need
- The sleeved main cables resist heat damage as well as fraying
- Fits any case conforming to the ATX standard
- Supports NVIDIA GPUs up to 3090 and AMD GPUs up to RX 6800 XT
- Zero RPM Fan mode silences the fan under low-load conditions
- Dynamic 120mm fluid-dynamic bearing fan
- 10-year warranty
Specification :
| OUTPUT CONNECTORS | 24-pin ATX power: 1
4 4-pin CPU power: 2 6 2-pin PCIe power: 6 SATA power: 6 Peripherals: 6 |
| CABLE SPECS | 24-pin ATX power: 600 mm, Nylon sleeving
4 4-pin CPU power: 700 mm, Nylon sleeving 6 2-pin PCIe power: 650 150 mm, Nylon sleeving SATA power: 500 150 mm Peripherals: 500 150 mm |
| AC INPUT RATING | 100 – 240Vac: 10A-5A 50Hz-60Hz |
| DC OUTPUT RATING | 3.3V and 5V: 22A (120W)
12V: 62.5A (850W) -12V: 0.3A (3.6W) 5Vsb: 3A (15W) Total: 750W |
| OPERATION | PF Correction: Active @0.96
MTBF:100,000 hours Temperature: 0 – 50 °C (derating from 100% to 80% from 40 °C to 50 °C) |
| ENERGY EFFICIENCY | Rating: 80 Plus Gold
20% loading: 87% @115Vac 50% loading: 90.5% @115Vac 100% loading: 87.5% @115Vac |
| Fan Specs | Dimensions: 135 x 135 x 25 mm
Speed: 0-2300 ± 10% RPM Airflow: 93.02 CFM (Tpy.) Noise: 44.5 dBA max Bearing: Fluid Dynamic Bearing (FDB) |
| GENERAL | Dimensions: 150 x 150 x 86mm
Material(s): Steel, PCB and Plastic Compliance Standard: ATX12V v2.52 / EPS12V v2.92 Regulation & Certification: cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA Model Number: PA-7G1BB-IN |
| Warranty | 10 years |
