SAPPHIRE NITRO AMD Radeon RX 6950 XT 16GB GDDR6 Graphic Card 11317-02-20G
Overview :
The NITRO AMD Radeon™ RX 6950 XT delivers powerhouse 4K gaming performance with vivid visuals for an elevated experience. The all-new innovative Wave Fin Design working in tandem with our V-Shape Fin Design for GPU Cooling reduces wind friction and centralizes airflow for optimal heat dissipation and a virtually silent system. Cutting edge Memory & VRM Cooling with Heat-Pipes and next gen K6.5 Memory Pad ensures you can push your performance to new limits while keeping the NITRO AMD Radeon™ RX 6950 XT components icy cool. The brand new Hybrid Fan Design combines the tranquility and strong air pressure features that exhibit ultimate levels of downward air pressure through the fan while keeping fan noise low. Incredible ARGB Lighting across the graphics card using our SAPPHIRE TriXX software fused with beautiful aesthetic styling will ensure the NITRO AMD Radeon™ RX 6950 XT is a stunning addition to every enthusiast gamer’s PC. NITRO Charge your PC with the NITRO AMD Radeon™ RX 6950 XT and elevate your gaming experience to the next level!
Specification :
| Model | |
| Brand | SAPPHIRE |
| Series | NITRO |
| Model | 11317-02-20G |
| Interface | |
| Interface | PCI Express 4.0 |
| Chipset | |
| Chipset Manufacturer | AMD |
| GPU Series | AMD Radeon RX 6000 Series |
| GPU | Radeon RX 6950 XT |
| Architechture | RDNA 2 |
| Game Clock | 2116 MHz |
| Boost Clock | 2324 MHz |
| Stream Processors | 5120 Stream Processors |
| Memory | |
| Memory Size | 16GB |
| Memory Interface | 256-Bit |
| Memory Type | GDDR6 |
| 3D API | |
| DirectX | DirectX 12 Ultimate |
| Ports | |
| Multi-Monitor Support | 4 |
| HDMI | 1 x HDMI |
| DisplayPort | 3 x DisplayPort 1.4 |
| Details | |
| Max Resolution | 7680 x 4320 |
| Virtual Reality Ready | Yes |
| Cooler | Triple Fans |
| System Requirements | PCI Express compatible motherboard with one x16 PCIe slot |
| Minimum 850W or greater power supply | |
| Minimum 8GB of system memory. Recommended 16GB | |
| Installation software requires a keyboard, a mouse, and a display | |
| A display with HDMI, or DisplayPort is required | |
| Supported operating systems include Linux, Windows 7/10/11. 64-bit operating system required | |
| * Windows 7 does not support all features including by not limited to Hardware Raytracing | |
| DirectX 12 and Vulkan support | |
| For information on AMD Radeon VR Ready Premium visit amd.com/VRready | |
| Recommended PSU Wattage | Minimum 850W or greater power supply |
| Power Connector | 2 x 8-Pin 1 x 6-Pin |
| Features | |
| Features | NITRO Product Features: |
| Software BIOS Switch | |
| NITRO Glow ARGB | |
| Fan Check | |
| Quick Connect Fan | |
| External RGB LED Synchronization | |
| Hybrid Fan Blade | |
| Wave Fin Design | |
| V-Shape Fin Design | |
| Integrated Cooling Module | |
| AMD Radeon Product Features: | |
| AMD RDNA 2 Architecture | |
| DirectX 12 Ultimate | |
| Hardware Raytracing | |
| 7nm GPU | |
| GDDR6 Memory | |
| PCI Express 4.0 Support | |
| AMD FreeSync Technology | |
| DisplayPort 1.4 w ith DSC | |
| HDMI | |
| Video Streaming up to 8K | |
| Radeon VR Ready Premium | |
| AMD FidelityFX | |
| Radeon Image Sharpening | |
| Radeon Anti Lag | |
| Radeon Software | |
| Game Driver Optimizations | |
| High Performance 4K Gaming | |
| Form Factor & Dimensions | |
| Form Factor | ATX |
| Max GPU Length | 320 mm |
| Card Dimensions (L x H) | 12.60″ x 5.31″ |
| Slot Width | 2.7 Slot |
| Packaging | |
| Package Contents | ACCESSORIES: |
| Graphics card supporter |
