Seagate Exos E 5U84
Overview :
Exos E Series – JBOD Building Blocks
Seagate Exos E 5U84 is the datasphere’s high-capacity, highperformance platform that can handle extreme data growth.
Modular Systems for Capacity
From reliability to intelligence, the Exos systems provide unfettered access to data and industry-first economics for lower TCO and highest capacity.
JBODS
High-capacity building blocks that easily grow with enterprises of any size.
Product Highlights
- Deliver peace of mind with features to protect data, including dual power supplies, fan modules, and I/O modules, as well as dual data paths to all drives
- Reduce power consumption with 80 PLUS Platinum certified power supplies and adaptive cooling technology
- Easily manage cables, universal ports, self-configuration controls, and standardized zoning
- Seamlessly expand to 336 drives as business grows
- Efficiently manage your data center with a 5U rackmount enclosure and unique drawer design that provides easy access to drives
- Maximum of 28.8GB/s in a dual controller configuration
Features :
Transfer Data Fast With a 12Gb/s SAS Interface
Get data to applications when and where it’s needed with up to 12Gb/s speed, unprecedented capacity, and effective maximum throughput of 14.4GB/s in a single I/O module or 28.8GB/s in a dual controller configuration. Even with expansion capability up to 336 hard drives or solid state drives, there is no sacrifice of space for performance.
Deliver Versatile Architecture Built to Grow
Minimize your TCO and store up to 1.1PB of data with an enclosure that leads the industry in both density and cost-forperformance while enabling easy expansion via interchangeable FRUs and SBB 2.0 compatibility. This flexible enclosure includes support and capabilities to manage cables, universal ports, self-configuration controls, and standardized zoning while helping you accelerate market introduction of new technologies and significantly simplify development and testing of storage implementations.
Ensure Applications Have Access to Critical Data
Safeguard your data with fault diagnosis, resolution capabilities, persistent error logging, and monitoring while ensuring maximum availability while harnessing high-availability features such as dual cooling, PCMs, and I/O modules, as well as dual data paths to all drives.
Reduce Cost and Resources With Energy-Efficient Features
This enclosure is suited for high-capacity, transaction-dependent environments that demand tighter Service Level Agreement (SLA) requirements and need faster response times for optimal data availability. It meets stringent worldwide requirements for recycling and environmental friendliness, and can help you minimize environmental impact and recognize cost savings through high performance while reducing power consumption with 80 PLUS Platinum certified adaptive cooling technology.
Build In Security at the Foundation of the Data Life Cycle
Protect your most valuable business assets with guaranteed compatible Seagate Secure™ hard drives.
Specification :
| Controller | Dual EBOD storage bridge bay (SBB) 2.1 compatible I/O modules per enclosure |
| Host/Expansion Interface | Three universal x4 12Gb/s mini-SAS connectors (SFF-8644) per I/O module |
| Management/Status Reporting | CLI via RS232 and 100Base-T port, SCSI enclosure services (SES) via SAS SFF-8644 ports |
| Maximum System Configuration | Dual host-connected enclosure with a maximum expanded configuration of 4 enclosures for a total of 336 drives |
| Device Support | Dual-ported 12Gb/s SAS |
| Max Drives per Enclosure | 84 (for a full list of supported drives, please contact your account or sales manager) |
| Hot-Swappable Components | Drives, power supply units (PSU), cooling modules, side planes, and SBB I/O modules |
| Physical | Height: 220mm / 8.65 in (5 EIA units) |
| Width: 483mm / 19 in (IEC rack compliant) | |
| Depth: 933mm / 36.75 in | |
| Weight: 135kg / 298 lb (with drives, no rail kit) | |
| Power Requirements-AC Input | |
| Input Power Requirements | 200V-240V AC 60Hz/50Hz |
| Environmental Requirements | |
| Operating/Nonoperating Altitude | -100m to 3000m (-330 ft to 10,000 ft) / -100m to 12,192m (-330 ft to 40,000 ft) |
| Temperature Range | 5°C to 35°C (de-rate 5°C above 2133m) |
| Humidity | 10% to 80% noncondensing |
| Operating/Nonoperating Shock | 5 Gs 10ms half sine (Z axis), 20 Gs 10ms half sine (X and Y axes) / 30 Gs 10ms half sine |
| Operating/Nonoperating Vibration | 0.21 Gs rms / 1.04 Gs rms |
| Standards/Approvals | |
| Safety Certifications | UL 60950-1 (USA and Canada) |
| EN 60950-1 (European Union) | |
| IEC 60950-1 (CB certification) | |
| Emissions (EMC) | FCC CFR 47 Part 15 Subpart B Class A (United States) |
| ICES/NMB-003 Class A (Canada) | |
| EN 55032 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3 (Europe) | |
| AS/NZS CISPR 32 Class A (Australia/New Zealand) | |
| VCCI Class A (Japan) | |
| KN 32 Class A/KN 35 (S. Korea) | |
| CNS 13438 Class A (Taiwan) | |
| Standard Marks/Approvals | North America (FCC, UL, cUL, ICES/NMB-003 Class A), Europe (CE), China (CCC – PSU only), Taiwan (BSMI), Korea (KC), Japan (VCCI), Australia/New Zealand (RCM – formerly C-tick) |
